Powering the new SZ is an all-new 4-Stroke air-cooled, SOHC single cylinder with 153cc engine that has been tuned for optimum performance i.e. Extra Power in the low to mid-speed range thereby ensuring a stress-free ride on Indian roads. The bikes are equipped with AI System and a large-capacity muffler with catalyzer for cleaner exhaust.

Engine

Engine type

Air-cooled, 4-stroke, SOHC

Displacement

153 cc

Bore & Stroke

58.0 × 57.9 mm

Compression ratio

9.5:1

Maximum power

12.1PS / 7,500 rpm

Maximum torque

12.8N.m / 4500 rpm

Starting system

Kick Start

Lubrication

Wet sump

Cylinder layout

Single cylinder

Ignition system

C.D.I.

Clutch type

wet, multiple disc

Fuel supply

Carburettor

Battery

12 V, 5 AH (10 AH)

Headlight

Halogen bulb (12 V, 35/35 W)

Primary/Secondary reduction ratios

3.409/3.000

Tranmission type

5 gear constant mesh

Caster/Trail

26 degree/99 mm

Gear ratios

1st=2.714, 2nd＝1.789, 3rd=1.318, 4th=1.045, 5th=0.916

Chassis

Frame type

Diamond

Front suspension

Telescopic

Rear suspension

Swingarm

Front brake

Drum (150 mm)

Rear brake

Drum (130mm Dia)

Front tyre

2.75-17 41P

Rear tyre

100/90-17 55P

Dimensions

Overall length x width x height

2,050mm x 730mm × 1,040mm

Kerb Weight

132 kg

Wheelbase

1,320mm

Minimum ground clearance

165mm

Engine oil volume

1.0 litres

Fuel tank capacity

14 liters

Seat Height

802 mm
