The product concept behind SZ-S is “Powerful & Comfortable! stylish Commuter, powering the new SZ-S is a 4-Stroke air-cooled, SOHC single cylinder with 153cc engine that has been tuned for optimum performance that is Extra Power in the low to mid-speed range thereby ensuring a stress-free ride on Indian roads. The bike is equipped with A I System and a large-capacity muffler with catalyzer for cleaner exhaust.

There is a large capacity 14L fuel tank which gives the ability to go Extra Mile. The long cushioned seat ensures comfortable riding position enabling a straighter back and Extra Comfort while commuting long distances. SZ-S is also equipped with some of the finest technologies like electric starter and a windscreen to cut inward air swirl, thus making a hassle free riding experience for the rider.

Adding to SZ-S charisma are the sophisticated meter panel, modern look dual tail lights, full plastic chain case (gives protection from dust & water), robust side cover and 5-spoke cast wheel.

Engine
Engine type
Air-cooled, 4-stroke, SOHC
Displacement
153 cc
Bore & Stroke
58.0 × 57.9 mm
Compression ratio
9.5:1
Maximum power
12.1PS / 7,500 rpm
Maximum torque
12.8N.m / 4500 rpm
Starting system
Electric Start + Kick Start
Lubrication
Wet sump
Cylinder layout
Single cylinder
Ignition system
C.D.I.
Clutch type
wet, multiple disc
Fuel supply
Carburettor
Battery
12 V, 5 AH (10 AH)
Headlight
Halogen bulb (12 V, 35/35 W)
Primary/Secondary reduction ratios
3.409/3.000
Tranmission type
5 gear constant mesh
Caster/Trail
26 degree/99 mm
Gear ratios
1st=2.714, 2nd=1.789, 3rd=1.318, 4th=1.045, 5th=0.916
Chassis
Frame type
Diamond
Front suspension
Telescopic
Rear suspension
Swingarm
Front brake
Drum (150 mm)
Rear brake
Drum (130 mm)
Front tyre
2.75-17 41P
Rear tyre
100/90-17 55P
Dimensions
Overall length x width x height
2,050mm x 730mm × 1,100mm
Kerb Weight
132 kg
Wheelbase
1,320mm
Minimum ground clearance
165mm
Engine oil volume
1.0 litres
Fuel tank capacity
14 liters
Seat Height
802 mm
