Crux, the complete economy 4-stroke bike gives unlimited mileage and unlimited pleasure. Its 106cc, 4-stroke engine, Strong Frame, attractive style, multi-reflector lights and long seat makes it the most comfortable & durable 4-stroke commuter bike on the Indian roads. With Over 4 lacs bikes already sold in India, Crux is winning the hearts of you all.

Engine
Engine type
Air-cooled, 4-stroke, SOHC, 2-valve
Cylinder arrangement
Single cylinder
Displacement
105.6cc
Bore & Stroke
49.0 x 56.0mm
Compression ratio
9.0:1
Maximum power
7.6PS (5.59kW) / 7,500rpm
Maximum torque
7.85N.m / 6,000rpm
Starting system
Kick start
Lubrication
Wet sump
Carburetion
VM17
Ignition system
C.D.I.
Primary / Secondary reduction ratio
3.722 / 3.143
Clutch type
Wet multi-plate coil spring
Transmission type
4-speed constant mesh
Gear ratios
1st=3.00, 2nd=1.688, 3rd:=1.200, 4th=0.875
Chassis
Frame type
Double cradle type, steel
Caster / Trail
26.4° / 83.4mm
Tire size (Front / Rear)
2.50 x 18" 4PR / 2.75 x 18" 6PR
Brake type (Front / Rear)
Drum (130mm Dia) / Drum (130mm Dia)
Suspension type (Front / Rear)
Telescopic / Swing arm
Battery capacity / Type
12V-2.5Ah
Headlight
12V 35/35W
Dimensions
Overall length x width x height
2,000mm x 735mm x 1,075mm
Seat height
780mm
Wheelbase
1,260mm
Minimum ground clearance
160mm
Dry weight / Kerb weight
103kg / 113kg
Engine oil capacit
1.0 liters
Fuel tank capacity
11 liters

Image 2

How is the Crux better than Herohonda CD dawn ?

Crux has a larger 105.6CC engine as compared to the CD Dawn's 97.2 CC engine for a better performance.Lower height of 780mm as compared to CD -Dawn's 805mm,results in wasy getting on and off the bike.The Crux has a larger wheelbase of 1260mm whereas the CD Dawn's is 1235mm which gives the Crux better stabilty and handling.

The Crux has an all metal body,What's the advantage of it ?

All metal body of the Crux is easier to maintain.In case of accident , the body panels can be easly repaired.Also the metal body gives a life long lasting gurantee

Why isn't the Crux been provided with an electric start ?

The crux is basically meant for rural usage where electric start can be a disadvantage sometimes.In case of any repairs, an electric start can be difficult to repair in rural areas.
