The Yamaha FZ Series set a new benchmark for biking. The FZ (FI) Series Version 2.0 takes it to the next level. It brings the most advanced Yamaha Blue Core concept to offer bikers an unmatched experience of performance and efficiency. At its heart is the all new Yamaha Fuel Injection(FI) engine. It uses advanced sensors and actuators to calculate and deliver the optimum amount of fuel to the engine – enhancing both performance and mileage. The reduced weight (132kg) makes the bike even more responsive leading to quick initial pickup and delivering smooth passing acceleration.
Specifications
Engine type
Air cooled, 4-stroke, SOHC, 2-valve
Displacement
149cc
Overall Length × Width × Height
1,990mm × 770mm × 1,030mm
Bore × Stroke
57.3mm x 57.9mm
Compression ratio
9.5:1
Maximum output
9.7 kW (13.1PS) / 8000 rpm
Maximum torque
12.8 N･m (1.3 kg f･m) / 6000 rpm)
Starting Method
Electric
Lubrication type
Force-feed lubrication, wet sump
Fuel Supply
Fuel injection
Clutch type
Wet, multiple-disc
Transmission type
Constant mesh 5-speed
Gear ratios
1st=2.714 2nd=1.789 3rd=1.318 4th=1.045 5th=0.875
Cylinder Layout
Single Cylinder
Battery
12V, 4.0AH (10H), Sealed type
Frame type
Diamond
Suspension (front/rear)
Telescopic / Monocross
Brake type(front/rear)
Disc/Drum
Tyre size (front)
100/80-17M/C (52P)NYLOGRIP ZAPPER-FX1 (Tubeless)
Tyre size (rear)
140/60-R17M/C (63P)revz-Y (Tubeless)
Headlight
12V, 35/35W
Turn signal light(Front/Rear)
12V,10W×2 / 12V,10W×2
Overall Length × Width × Height
1,990mm × 770mm × 1,030mm
Seat height
790 mm
Wheelbase
1,330 mm
Minimum ground clearance
160mm
Kerb weight
132 kg
Fuel tank volume
12 litres
