DIMENSION & WEIGHT
Overall length X width X height
1,835x675x1,090mm
Seat height
760mm
Wheelbase
1,270mm
Minimum ground clearance
128mm
Weight (with oil and a full fuel tank)
104kg
ENGINE PERFORMANCE
Engine type
Air cooled, 4-stroke, SOHC, 2-valve with CVT
Cylinder arrangement
Single cylinder
Displacement
113cc
Bore & stroke
50.0x57.8mm
Maximum output
7.1PS/7500rpm
Maximum torque
8.1Nm/5000rpm
Starting system type
Electric and Kick
FUEL
Fuel tank capacity
5L
Fuel supply
Carburetorr
ELECTRICAL
Ignition system type
CDI(Capacitor Discharge lgnition)
Battery voltage/capacity
12V,5.0Ah(10H)
TRANSMISSION
Clutch type
Dry, Centrifugal
BRAKE
Brake type (Front/Rear)
Drum brake,130mm diameter
TYRES
Tyre Size (Front)/(Rear)
90/100-10 53 J (Tube Type)
SUSPENSION
Suspension type (Front/Rear)
elescopic/Unit swing
